unity Joystick

1
using System.Collections;
2
using System.Collections.Generic;
3
using UnityEngine;
4

5
public class GameManager : MonoBehaviour
6
{
7
    public UIVirtualJoystick joystick;
8
    public Transform trans;
9
    public float moveSpeed = 1f;
10

11
    // Start is called before the first frame update
12
    void Start() { }
13

14
    // Update is called once per frame
15
    void Update()
16
    {
17
        Vector2 joystickDirection = joystick.direction;
18

19
        Vector3 movement = new Vector2(joystickDirection.x, joystickDirection.y);
20

21
        trans.position += movement * moveSpeed * Time.deltaTime;
22
    }
23
}

1
using UnityEngine;
2
using UnityEngine.Events;
3
using UnityEngine.EventSystems;
4

5
public class UIVirtualJoystick : MonoBehaviour, IPointerDownHandler, IDragHandler, IPointerUpHandler
6
{
7
    [System.Serializable]
8
    public class Event : UnityEvent<Vector2> { }
9

10
    [Header("Rect References")]
11
    public RectTransform containerRect;
12
    public RectTransform handleRect;
13

14
    [Header("Settings")]
15
    public float magnitudeMultiplier = 1f;
16
    public bool invertXOutputValue;
17
    public bool invertYOutputValue;
18
    public bool useCircularInput = true;
19

20
    [Header("Output")]
21
    public Vector2 direction;
22
    public Event joystickOutputEvent;
23

24
    private float joystickRadius;
25
    private bool isPointerDown = false; // 新增：标记是否在有效点击范围内
26

27
    void Start()
28
    {
29
        joystickRadius = containerRect.sizeDelta.x * 0.5f;
30

31
        UpdateHandleRectPosition(Vector2.zero);
32
    }
33

34
    public void OnPointerDown(PointerEventData eventData)
35
    {
36
        if (useCircularInput)
37
        {
38
            isPointerDown = false;
39
            RectTransformUtility.ScreenPointToLocalPointInRectangle(
40
                containerRect,
41
                eventData.position,
42
                eventData.pressEventCamera,
43
                out Vector2 localPoint
44
            );
45

46
            if (localPoint.magnitude > joystickRadius)
47
            {
48
                return;
49
            }
50
        }
51

52
        isPointerDown = true;
53

54
        OnDrag(eventData);
55
    }
56

57
    public void OnDrag(PointerEventData eventData)
58
    {
59
        // 如果不在有效点击范围内，则忽略
60
        if (!isPointerDown)
61
            return;
62

63
        RectTransformUtility.ScreenPointToLocalPointInRectangle(
64
            containerRect,
65
            eventData.position,
66
            eventData.pressEventCamera,
67
            out Vector2 position
68
        );
69

70
        position = position / joystickRadius;
71

72
        Vector2 clampedPosition = Vector2.ClampMagnitude(position, 1f);
73

74
        Vector2 outputPosition = ApplyInversionFilter(clampedPosition);
75

76
        direction = outputPosition * magnitudeMultiplier;
77
        joystickOutputEvent.Invoke(direction);
78

79
        if (handleRect)
80
        {
81
            UpdateHandleRectPosition(clampedPosition * joystickRadius);
82
        }
83
    }
84

85
    public void OnPointerUp(PointerEventData eventData)
86
    {
87
        direction = Vector2.zero;
88
        joystickOutputEvent.Invoke(Vector2.zero);
89

90
        if (handleRect)
91
        {
92
            UpdateHandleRectPosition(Vector2.zero);
93
        }
94
    }
95

96
    private void UpdateHandleRectPosition(Vector2 newPosition)
97
    {
98
        handleRect.anchoredPosition = newPosition;
99
    }
100

101
    private Vector2 ApplyInversionFilter(Vector2 position)
102
    {
103
        if (invertXOutputValue)
104
        {
105
            position.x = -position.x;
106
        }
107

108
        if (invertYOutputValue)
109
        {
110
            position.y = -position.y;
111
        }
112

113
        return position;
114
    }
115
}
